Publications
- Vezhnevets V., Konouchine V.,
"Grow-Cut" - Interactive Multi-Label N-D Image Segmentation.
Accepted to Graphicon-2005.
.pdf (871kb)
Downloads
Introduction
Image segmentation is an inherent part of important image
processing applications like automated medical images analysis and
photo editing. Also, a wide range of computational vision problems
could benefit from existence of reliable and efficient image
segmentation technique. For instance, intermediate-level vision
problems such as shape from silhouette, shape from stereo and
object tracking in video could make use of reliable segmentation
of the object of interest from the rest of the scene. Higher-level
problems such as recognition and image indexing can also make use
of segmentation results in matching.
Fully automated segmentation techniques are being constantly
improved, however, current state-of-the art is such that no
automated image segmentation technique can be applied fully
autonomously with reliable results in general case. That is why
semi-automatic segmentation techniques that allow solving moderate
and hard segmentation problems by modest interactive effort on the
part of the user are becoming more and more popular.
Related work
Current state of the art interactive segmentation tools can be loosely
divided into two families - applied to generic images, and designed especially for medical images processing.
Generic image segmentation tools include:
- Magic Wand - is a common selection tool for almost any
image editor nowadays. It gathers color statistics from the
user-specified image point (or region) and segments
image region with pixels, which color properties
fall within some given tolerance of the gathered statistics.
- Intelligent Paint
is region-based interactive segmentation technique,
based on hierarchical image segmentation by toboganning.
The strategy it uses coordinates human-computer interaction to extract
regions of interest from backgrounds using paint strokes
with a mouse.
- Intelligent Scissors (Magnetic Lasso)
- is a boundary-based method, that computes
minimum-cost path via shortest-path graph algorithms between
user-specified boundary points.
- Graph Cut
is a combinatorial optimization technique, which was
applied to the task of image segmentation. For the case of
two labels (i.e. object and background) the globally optimal
pixel labelling can be
efficiently computed by max-flow/min-cut algorithms.
- GrabCut
extends graph-cut by introducing iterative segmentation
scheme, that uses graph-cut for intermediate steps. The user
draws rectangle around the object of interest. Each iteration
step estimates color statistics of object and background and applies graph-cut
to compute new refined segmentation.
-
Random walker - given a small number of pixels with user-defined
seed labels, this method analytically determines the probability
that a random walker starting at each unlabeled pixel will
first reach one of the pre-labeled pixels. By assigning each
pixel to the label for which the greatest probability is calculated,
image segmentation is obtained.
Proposed method
Our proposed method uses completely different instrument (Cellular
Automaton) for solving pixel labelling task, starting from small
number of pixels with user-specified seed labels. We take a popular
user interaction scheme - user place several seeds (or loosely
paints with `seed brush') inside the object(s) in the image that should be segmented
from each other. Similar scheme is used by other authors and both
by their and our own experiments has proven to be easy for
the user to master and allows fast achievement of the desired result.
Our method is iterative, giving feedback to the user as the segmentation
is computed. Our method allows (but not requires) human
input during labelling process to provide dynamic interaction
and feedback between the user and the algorithm. This allows human
input to correct and guide the algorithm where the segmentation
is difficult to compute, yet does not require additional user
effort where the segmentation is easy to computed automatically.
Photo editing examples
More complicated examples. These examples were created by our interactive implementation.
Average time for an average user to achieve the shown results is 15 to 25 seconds.
